RGB LED Lamp

Create an RGB LED lamp with an Arduino.

RGB LED Lamp

A simple project using an Arduino that will allow you to create an RGB LED lamp.

All that you need for this project is an Arduino and an RGB LED.

Here you can download the code for the Arduino: Arduino code

Steps

Step #1: Electronic Sketch.

PrevNext
RGB LED Lamp
  • The RED pin is attached to pin 9
  • The GREEN pin is attached to pin 6
  • The BLUE pin is attached to pin 5
  • The BLACK pin is atteched to GND

Step #2:

PrevNext
RGB LED LampRGB LED LampRGB LED Lamp

The gray cable is obviously the ground.

Step #3:

PrevNext
RGB LED LampRGB LED LampRGB LED LampRGB LED Lamp

The three colours in series. There is a small fade between one colour and the next.
